High Pf 24v 80w Constant Voltage Led Power Supply

Product Description

High PF 24v 80w Constant Voltage Led power supply

Fuso supply the China high PF 24V 80w constant voltage LED power supply, model SLG-80V-24A, with an input range of AC100~277V and an output of 24V, delivering a rated power of 80w. This model features a high power factor of >0.9, which reduces reactive current consumption from the grid, ensuring more efficient energy use. Fuso, with 18 years of experience as a professional manufacturer of high PF 24V 80w constant voltage LED power supplys, is committed to providing tailored solutions to meet the unique needs of our clients. Our products are widely used across European, American, Asian, and Australian markets, and we are eager to establish long-term partnerships worldwide.

Product Introduction of high PF 24V 80w constant voltage Led power supply

The TLG-80V-24A high PF 24V 80w constant voltage LED power supply is designed for energy efficiency, boasting a power factor greater than 0.95. It includes over-voltage, over-temperature, and short-circuit protection to ensure safe operation. Customizable dimming options such as Triac and 0-10V dimming are available to meet specific requirements. With an all-aluminum housing and IP67-rated waterproof and dustproof protection, this High PF 24v 80w Constant Voltage Led power supply is built for durability in any environment. Meeting CE, RoHS, TUV, UL, ETL, GS, CCC, and SAA certifications, Fuso’s 18 years of experience ensures the highest quality LED power solutions for applications worldwide.

High PF 24v 80w Constant Voltage Led power supply

Product Parameter (Specification) of high PF 24v 80w Constant Voltage Led power supply

SPECIFICATION

MODEL

TLG-80V-12A

TLG-80V-24A

TLG-80V-36A

TLG-80V-42A

TLG-80V-54A

INPUT

Voltage Range

100-305VAC

Frequency Range

47-63Hz

Power Factor

PF≥0.98/100VAC, PF≥0.95/220VAC, PF≥0.92/277VAC @full load

Efficiency

85.00%

87.00%

88.00%

90.00%

91.00%

AC Current

0.7A/ 115VAC / 0.35A/230VAC / 0.3A/277VAC

Inrush Current

25Amax.@Full Load,230VAC,Cold Start

Circuit Breaker

2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC

Leakagel Current

<1mA / 277VAC

OUTPUT

DC voltage

12VDC

24VDC

36VDC

42VDC

54VDC

Output rated current

8-12V

14.4-24VA

21.6-36VA

25.2-42A

32.4-54A

Rated power

80W

80.25W

Ripple & Noise

120mVp-p

150mVp-p

200mVp-p

300mVp-p

Voltage adjustment range

10.5-14V

22-27V

33-40V

40-46V

49-58V

Current adjustment range

1.5-2.5A

0.75-1.25A

0.5-0.84A

0.4-0.72A

0.3-0.56A

Voltage accuracy

士 2.0%

士 1.0%

Linear adjustment rate

士 1.0%

Load regulation ratio

士 1.5%

Start, rise time

800ms,80ms/115VAC，500ms,50ms/230VAC@full load

Hold time (typ.)

30ms/115VAC，230VAC

PROTECTION

Over Current

95-110%, constant current limit, automatic recovery after abnormal load conditions are removed

Over Voltage Protection

16-18V

28-35V

41-49V

48-58V

59-68V

Turn off output voltage, restart recovery

Short circuit Protection

Hiccup mode, which can be automatically restored after the abnormal load condition is removed

Over Temperature

Turn off output voltage, restart recovery

ENVIRO
NMENT

Working Temp

Tcase=-40℃…+70℃

Max. Case Temp

Tcase= +90℃

Working Humidity

20-95% RH,No condensation

Storage Temp

-40...+80℃, 10...95% RH,No condensation

Vibration

10-500Hz,2G10min./1cycle,60min.eachalongX,Y,Zaxes

SAFETY &
EMC

Safety Standards

Conform UL8750(type”TL”)，CSA C22.2 No. 250.0-08，BS EN/EN/AS/NZS 61347-1，
BS EN/EN/AS/NZS 61347-2-13，independent，GB19510.1，GB19510.14，
EAC TPTC 004，KC61347-1，IP67

Withstand Voltage

I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC

Insulation impedance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH

Electromagnetic
Compatibility

Conform BS EN/EN55015, BS EN/EN61000-3-2 Class C (@Load>60%) ;
BS EN/EN61000-3-3,GB/T 17743, GB17625.1, EAC TPTC 020

Electromagnetic compatibility
immunity

Conform BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547,Light industry standards
(Surge immunity: wire-to-ground4KV,Line-to-line:2KV), EAC TPTC 020

OTHERS

MTBF

>3000K hrs. MIL-HDBK-217F (25℃)

Dimension

(L) 180 mm*(W) 62 mm*(H) 36 mm

NOTE

1: Please refer to "LED Module Driving Method".
2: Ripple and noise measurement method: Use a 12 "twisted pair, and the terminals must be connected in parallel with 0.1 uf and 47uf capacitors, and measure at 20MHZ bandwidth.
3: Type B only adjustable (through internal potential adjustment).
4: Accuracy: including setting error, linear adjustment rate, and load adjustment rate.
5: Unless otherwise specified, all specifications are measured at 230VAC input, rated load, and 25 °C ambient temperature.
6: The power supply is regarded as a component used in combination with the terminal equipment. Because the EMC is affected by the entire device, the terminal equipment manufacturer needs to re-confirm the EMC of the entire device.

Product Details of high PF 24v 80w Constant Voltage Led power supply

Size of 24v 80w constant voltage led power supply

Equipment & instruments

Production Process

Product Applications of high PF 24v 80w Constant Voltage Led power supply

high PF 24v 80w Constant Voltage Led power supply Applications

Product Packaging and Shipping

High PF 80w Constant voltage Led power supplyhas a strong packaging design, it will not be worn or broken during transportation, which can ensure the product reach your hand safely.

Container Loading&Shipment

Installation Precautions:

1. Please follow the correct input voltage range for installation;

2. Make sure AC input line, DC output line, DIM signal line connect correctly.

FAQ

1.Are you a factory or trading company?
We are a factory, we provide ODM& OEM services.
2.What is your main product line is made?
We mainly produce constant current led power supply ,constant voltage led power supply, and dimmable led power supply

3. You have the ability to do independent research and development?
The core members of our engineering departmenthave 12-18 years in the LED field, who can give more professional and reliable advice and solution andwe have the R&D ability to make our products competitive. We also collect regularly customer feedback, products improvement and new product requirement. We also hold monthly new product launches.
4. What certificates you have?
UL, ENEC, TUV, CE, RoHS, CB, SAA, KC, PSE, BIS and CCC certifications etc.
5.What is your production capacity?
5,0000-10,000pcs per month
6.What is the warranty?
Most of our products are 5 years warranty.
7.How about the delivery time ?
Delivery time for sample:3-5days after get your samples request and samples charge.
Delivery time for mass production: 10-18days after order confirmed after receiving buyer's deposit
8.How do you handle defects?
1/1 replacement of defects within the warranty period.
9.How about the Package & Product design?
Based on factory original box,original design on product with neutral laser and label,original package for export carton.If need your mark on products or packing, please tell us, we can do it for you.
