Product Description

50W Customized LED Driver Of Corn Lamp

The VCG-50C-42A is a 50W customized led bulb light driver designed to provide reliable and efficient lighting solutions. This driver is engineered to meet the demands of various lighting applications with its robust features.The VCG-50C-42A accommodates a wide input voltage range of 100-305V, ensuring compatibility with different power systems and enhancing its versatility.It delivers an output voltage of 36-54V, which is ideal for LED bulb lights and ensures consistent performance across different bulbs.With a power factor greater than 0.95, the VCG-50C-42A contributes to energy efficiency, reducing power loss and improving the overall effectiveness of the lighting system.The customized led driver is designed to operate without flicker, providing a stable and comfortable lighting environment, which is crucial for visual comfort and reducing eye strain.It includes overvoltage protection to safeguard the LED globe lights from voltage spikes, ensuring the longevity and safety of the lighting system.

The VCG-50C-42A is built to withstand high temperatures, making it suitable for environments with varying temperature conditions.Equipped with surge protection, this driver can handle power surges, further protecting the lighting system from potential damage.

Backed by a 5-year warranty, the VCG-50C-42A is a reliable choice for long-term lighting solutions. VCG-50C-42A customized led driver is a testament to the commitment to quality and performance, making it an excellent choice for a variety of lighting applications, including indoor and outdoor use. Its reliability and efficiency are further enhanced by the certifications it complies with, ensuring safety and environmental standards are met.

Product Introduction of 50W Customized LED Driver Of Corn Lamp

The VCG-50C-42A is a 50W customized led bulb light driver, meticulously engineered for use in LED bulb lamps. This bareboard driver is tailored to meet the specific requirements of our clients and boasts a range of features that make it a standout choice in the market,

The VCG-50C-42A is compliant with a suite of international safety and environmental standards, including CE, RoHS, TUV, UL, ETL, GS, CCC, SAA, PSE, FCC, and CCC. These certifications ensure that the product meets the highest quality and safety requirements globally.It offers full-voltage input capability, making it versatile for use across different power systems.The customized led driver contributes to energy efficiency by reducing power loss, with a high power factor that is crucial for the overall effectiveness of the lighting system.

Flicker-Free Operation: Designed to operate without flicker, the VCG-50C-42A ensures a stable and comfortable lighting environment, which is essential for visual comfort and reducing eye strain.

Built to withstand high temperatures, Thed coustomized led driver is suitable for environments with varying temperature conditions.

High PF 24V 80w Constant Voltage Led driver

The VCG-50C-42A includes surge protection, safeguarding the LED bulb lights from power surges and potential damage.

We stand by the quality and performance of our product, offering a 5-year warranty that reflects our commitment to durability and reliability.

FUSO Company which manufactures the VCG-50C-42A, operates under the ISO9001:2005 quality management system, ensuring top-tier production standards。 With 18 years of production and design experience, FUSO has exported to over 50 countries, specializing in the production of various high-power IP65 and IP67 waterproof LED drivers. The company's main business is to customize a variety of LED drivers according to customer requirements, including Dimmable Led Driver, Triac Dimmable Led Driver, Contact Current LED driver, and Constant Voltage LED driver。 These products are widely applied in LED indoor lighting, LED downlights, LED ceiling lights, LED line lights, LED table lamps, LED light strips, LED flexible light strips, LED underwater lights, LED underground lights, LED projection lights, LED corrugated lights, LED wall washers, LED neon tubes, LED line lights, LED architectural lighting, LED navigation lights, LED display lights, LED advertising lights, LED mirror lights, LED film and television lights, and LED stage lights, among others.

Product Parameter (Specification) of 50W Customized LED Driver Of Corn Lamp

SPECIFICATION

MODEL

VCG-50C-30A

VCG-50C-36A

VCG-50C-42A

VCG-50C-48A

VCG-50C-54A

INPUT

Voltage Range

100-305VAC

Frequency Range

47-63Hz

Power Factor

PF≥0.98/100VAC, PF≥0.95/220VAC, PF≥0.92/277VAC @full load

Efficiency

85.00%

87.00%

88.00%

90.00%

90.50%

AC Current

0.45A/ 115VAC / 0.22A/230VAC

Inrush Current

25Amax.@Full Load,230VAC,Cold Start

Circuit Breaker

2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC

Leakagel Current

<1mA / 277VAC

OUTPUT

DC voltage

30VDC

36VDC

42VDC

48VDC

54VDC

Output rated current

24-30VA

30-36VA

36-42VA

40-48A

48-54A

Rated power

50W

Ripple & Noise

120mVp-p

150mVp-p

200mVp-p

300mVp-p

Voltage adjustment range

24-30V

30-36V

36-42V

40-48

48-54

Voltage accuracy

士 2.0%

士 1.0%

Linear adjustment rate

士 1.0%

Load regulation ratio

士 1.5%

Start, rise time

800ms,80ms/115VAC，500ms,50ms/230VAC@full load

Hold time (typ.)

30ms/115VAC，230VAC

PROTECTION

Over Current

95-110%, constant current limit, automatic recovery after abnormal load conditions are removed

Over Voltage Protection

24-30V

30-36V

36-42V

40-48

48-54

Turn off output voltage, restart recovery

Short circuit Protection

Hiccup mode, which can be automatically restored after the abnormal load condition is removed

Over Temperature

Turn off output voltage, restart recovery

ENVIRO
NMENT

Working Temp

Tcase=-40℃…+70℃

Max. Case Temp

Tcase= +90℃

Working Humidity

20-95% RH,No condensation

Storage Temp

-40...+80℃, 10...95% RH,No condensation

Vibration

10-500Hz,2G10min./1cycle,60min.eachalongX,Y,Zaxes

SAFETY &
EMC

Safety Standards

Conform UL8750(type”TL”)，CSA C22.2 No. 250.0-08，BS EN/EN/AS/NZS 61347-1，
BS EN/EN/AS/NZS 61347-2-13，independent，GB19510.1，GB19510.14，
EAC TPTC 004，KC61347-1，IP20

Withstand Voltage

I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC

Insulation impedance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C/ 70% RH

Electromagnetic
Compatibility

Conform BS EN/EN55015, BS EN/EN61000-3-2 Class C (@Load>60%) ;
BS EN/EN61000-3-3,GB/T 17743, GB17625.1, EAC TPTC 020

Electromagnetic compatibility
immunity

Conform BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN61547,Light industry standards
(Surge immunity: wire-to-ground4KV,Line-to-line:2KV), EAC TPTC 020

OTHERS

MTBF

>3000K hrs. MIL-HDBK-217F (25℃)

Dimension

φ70 mm*(H) 26mm

NOTE

1: Please refer to "LED Module Driving Method".
2: Ripple and noise measurement method: Use a 12 "twisted pair, and the terminals must be connected in parallel with 0.1 uf and 47uf capacitors, and measure at 20MHZ bandwidth.
3: Type D only adjustable (through internal potential adjustment).
4: Accuracy: including setting error, linear adjustment rate, and load adjustment rate.
5: Unless otherwise specified, all specifications are measured at 230VAC input, rated load, and 25 °C ambient temperature.
6: The power supply is regarded as a component used in combination with the terminal equipment. Because the EMC is affected by the entire device, the terminal equipment manufacturer needs to re-confirm the EMC of the entire device.

Product Details of 50W Customized LED Driver Of Corn Lamp

Equipment & instruments

Production Process

Product Applications of 50W Customized LED Driver Of Corn Lamp

Product Packaging and Shipping

50W Customized LED Driver Of Corn Lamp has a strong packaging design,it will not be worn or broken during transportation, which can ensure the product reach your hand safely.

Container Loading&Shipment

Installation Precautions:

1. Please follow the correct input voltage range for installation;

2. Make sure AC input line, DC output line, DIM signal line connect correctly.

FAQ

1.Are you a factory or trading company?
We are a factory, we provide ODM& OEM services.
2.What is your main product line is made?
We mainly produceconstant current led driver ,constant voltage led driver, and dimmable led driver

3. You have the ability to do independent research and development?
The core members of our engineering department have 12-18 years in the LED field, who can give more professional and reliable advice and solution and we have the R&D ability to make our products competitive. We also collect regularly customer feedback, products improvement and new product requirement. We also hold monthly new product launches.
4. What certificates you have?
UL, ENEC, TUV, CE, RoHS, CB, SAA, KC, PSE, BIS and CCC certifications etc.
5.What is your production capacity?
5,0000-10,000pcs per month
6.What is the warranty?
Most of our products are 5 years warranty.
7.How about the delivery time ?
Delivery time for sample:3-5days after get your samples request and samples charge.
Delivery time for mass production: 10-18days after order confirmed after receiving buyer's deposit
8.How do you handle defects?
1/1 replacement of defects within the warranty period.
9.How about the Package & Product design?
Based on factory original box,original design on product with neutral laser and label,original package for export carton.If need your mark on products or packing, please tell us, we can do it for you.
